Carbon Fiber Telescopic Pole — 3K Twill, 25 mm, Water Fed Ready

A carbon fibre telescopic pole earns its price at full extension. At twelve metres an aluminium pole begins to whip, and every movement of the operator's shoulder is transmitted to the brush head. A carbon pole of the same length stays straight, so the brush lands where it is placed and the glass is finished in fewer passes. For crews working water-fed windows, solar arrays or gutters from the ground, that difference appears as less fatigue by mid-afternoon and fewer callbacks.

Characteristics

- 100% 3K twill or plain weave carbon fibre, roll-wrapped construction
- Tube outer diameter 25 / 28 / 32 mm, wall thickness 1.0 / 1.2 / 1.5 mm
- 4 to 10 sections, working length from 3 m to 18 m
- Twist-lock or lever clamp, fully replaceable
- Glossy or matte UV-stable finish
- Every individual section available as a spare part
Technology

Each tube is roll-wrapped around a mandrel and cured under controlled temperature, with fibre orientation set at 0° and 90° to balance bending stiffness against hoop strength. The stiffness of a telescopic pole is governed mainly by outer diameter and wall thickness rather than by fibre grade alone. This is why every model is quoted with its OD and wall dimension instead of a single high-modulus claim.

Application

Water-fed window cleaning, solar panel washing, gutter vacuum work, high dusting in warehouses and atria, and general long-reach tasks such as signage and mast support.

Specification

Model Sections Extended Collapsed OD Wall Weight CF-25-4 4 3.0 m 0.90 m 25 mm 1.0 mm 0.75 kg CF-25-6 6 7.2 m 1.35 m 25 mm 1.0 mm 1.25 kg CF-28-8 8 12.0 m 1.70 m 28 mm 1.2 mm 2.10 kg CF-32-10 10 18.0 m 2.10 m 32 mm 1.5 mm 3.40 kg

Service

OEM lengths, printed logo on the clamp, custom tube colour and retail carton are available. Sample lead time is 7 days; bulk production is 25 to 30 days. Spare sections ship with every order so a damaged tube does not idle a crew.

FAQ

Can the pole be used with water? Yes. Water-fed models include an internal hose channel and a threaded top fitting for standard brush heads.

Are spare sections available? Yes, every section is stocked and sold separately.

What is the minimum order? 50 pieces for stock models, 100 pieces for custom printing.

Send us your working height and brush fitting, and we will confirm the matching model within one working day.
